PT-4500H-568CED Blind Bolt Installation Kit, 5/32 inch to 1/4 inch

Description

The PT-4500H-568CED battery-operated cordless installation tool kit provides ergonomic design with optimum speed and reliability for installation of single-action aerospace blind bolts (MS90353/54 S/U and MS21140/41 S/U) thru 1/4" diameter. Its distinguishing feature is the patented close edge distance nose assemblies, which allow fasteners to be set nearer to a panel edge or adjacent structure than standard nose tooling permits — the reason this kit gets specified for light production, MRO, battle damage repair and mobility kit use.

The riveter is not limited to blind bolts: with the appropriate HUCK style nose assemblies it installs most single-action blind rivets and lockbolts as well. Using the F4187-AR-4500 rotating adapter, Huck 3700 series offset nose assemblies attach easily. The kit ships in a foamed carrying case with everything needed to work immediately.

Specifications

• Pull Force: 5,000 lbs (22.24 kN)
• Stroke: 0.984" (25 mm)
• Motor Type: Brushless
• Power Source: 18 VDC, 2.1 Ah Li-Ion with fuel gage
• Weight (with battery): 4.725 lbs (2.143 kg)
• Tool Dimensions: 11.5" H x 12" L x 3.25" W
• Vibration: <2.5 m/s²
• Noise: Lpa 78.5 dB(A)
• Operating Temp Range: 50°F to 122°F (10°C to 50°C)
• Charger: 100–240 V, 50–60 Hz input; 21 V / 2.5 A output; 40 min charge cycle
• Certifications: UL® and CE approved

Kit Contents

• PT-4500H cordless riveter
• 5/32" close edge distance nose assembly
• 3/16" close edge distance nose assembly
• 1/4" close edge distance nose assembly
• 2 × 18 VDC Li-Ion battery packs
• 110 V / 220 V battery charger
• Foamed carrying case

Related Dedicated Tools

• PT-4500H-4301-05CED — 5/32" blind bolt
• PT-4500H-4307-06CED — 3/16" blind bolt
• PT-4500H-4313-08CED — 1/4" blind bolt

Applications: Aerospace blind bolt installation at close edge distances, light production, MRO, battle damage repair, mobility kits.
