K-1000-2 Sheet Metal Material & Hole Preparation Kit

Description

The K-1000-2 is the hole preparation module of the K-1000 system, and it is the one that determines whether the finished repair holds. Hole quality — diameter, roundness, countersink depth and edge distance — drives the fatigue life of every fastener installed into it, so this kit is built around precision locating and controlled cutting rather than general drilling.

The 110 items cover the full preparation sequence. ALHF hole finders in bushing and inverted types locate existing holes from #40 through 1/4″; twelve F518 nutplate jigs position rivet holes off the fastener centreline; ALTD threaded drill bits and ALTR threaded reamers cut to size; and the F590 micro-stop countersink kit with the F590DBK drill bushing kit controls countersink depth repeatably. Threaded angle drills in 45° and 90° reach fastener locations a pistol drill cannot, and clecos with edge grip clamps hold the work while it is cut.

Specifications

• National Stock Number: 5180-01-584-5838
• Trays: 4, router-cut foam
• Total Items: 110
• Hole Size Range: #40 through 1/4″ diameter

Kit Contents

• ALHF hole finders, bushing and inverted types, #40 through 1/4″
• 12 × F518 nutplate jigs
• Clecos in four sizes with F74 cleco pliers; F121SG and F1212SG edge grip clamps
• ALTD threaded drill bits, ALJBD cobalt drill bits, ALTR threaded reamers
• F10101, F10102 and F10103 Unibits
• FSD2800-45T and FSD2800-90T threaded angle drills
• F590 micro-stop countersink kit and F590DBK drill bushing kit
• Sanding drums and abrasive pads; FOS-50CNP orbital sander
• FSN1444 pneumatic nibbler and F04076 sealant gun
• D-180 hand hydraulic riveter

Please note: this kit is one of the three modules that make up the complete K-1000 Sheet Metal Mechanics Tool Kit (NSN 5180-01-586-1897). It is stocked and sold individually under its own National Stock Number, and can also be supplied as part of the full three-box system or in the K-1000-H roll-around hangar box.

Applications: Aircraft hole preparation, nutplate location, countersinking to depth, skin replacement and patch fitting.
